We have gained expertise in offering General Purpose Beltings to the customers that are made in compliance with the international quality standards. These Beltings are widely used for the transportation of heavy, sharp & highly abrasive materials from one place to another.
Moreover, owing to their high tensile strength and superior resistance to abrasion, these products are highly demanded in the market.
GRADE M24
This is recommended for handling highly abrasive materials and has good resistance to cutting and gouging.
Applicable Standards: IS 1891 (Part-I).
GRADE N17
This is recommended for handling moderately abrasive material.
Applicable Standards: IS 1891 (Part-I).
These are used to carry the following
- Iron ore
- Coal
- Copper
- Limestone
- Lignite
- Sand
- Cement
- Wood chips
- Dry pulp
COVER GRADE SELECTION CHART
| Country | Reference Standard | Cover Grade | Tensile Strength, MPa | Elongation at break, % | Abrasion loss, mm³ |
| India | IS 1891 Part 1 | M 24 | 24 | 450 | 150 |
| N 17 | 17 | 400 | 200 | ||
| Germany | DIN 22102 | W | 18 | 400 | 90 |
| X | 25 | 450 | 120 | ||
| Y | 20 | 400 | 180 | ||
| Z | 15 | 350 | 250 | ||
| United Kingdom | BS 340 | M 24 | 24 | 450 | 150 |
| N 17 | 17 | 400 | 200 | ||
| Australia | AS 3213 | A | 17 | 400 | 70 |
| M | 24 | 450 | 125 | ||
| N | 17 | 400 | 200 | ||
| South Africa | SANS 1173 | A | 18 | 400 | 70 |
| M | 24 | 450 | 120 | ||
| N | 20 | 400 | 150 |
